Details
What Makes it a P9 Performance?
- Bosch Performance Sport motor provides up to 65 Nm of torque and 300% support, max speed up to 28 mph
- 1x9-speed Shimano Alivio groupset with trigger shifter
Quick Haul Highlights
- Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack
- Fits riders 160—195 cm (5'3"—6'5"), and also riders 145—180 cm (4'9"—5'11") when equipped with a shorter, 350 mm seatpost
- Lots of available kid- and cargo-carrying accessories-easily create your perfect setup
- Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
- Shimano hydraulic disc brakes for reliable stopping power-even when heavily loaded and riding fast
- Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Specs
Frame | Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg |
---|---|
Fork | Cargo, steel, EFBE approved: 150 kg |
Rims | Kinetix Comp, for disc |
Hubs | Shimano Disc |
Spokes | Stainless Steel |
Tires | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
Bottom Bracket | Motor integrated |
Crankset | Tern custom, forged 6061-AL crankarm |
Shifters | Shimano Alivio, 1 x 9 spd, trigger |
Rear Derailleur | Shimano Alivio Shadow |
Cassette/Freewheel | Shimano 11-34T, 9 spd |
Chain | KMC for eBike, 9 spd |
Brakes | Shimano, hydraulic disc |
Brake Levers | Shimano, hydraulic disc |
Handlebars | Low riser, 31.8, 6061-AL |
Tape/Grips | Velo ergonomic, lock-on |
Stem | Speedlifter, 150 mm extension, 3D Forged stem, 31.9 |
Headset | TH, cartridge bearings |
Seatpost | 31.6 mm, 6061-AL, micro-adjust clamp |
Saddle | Velo Comfort |
Pedals | Urban with non-slip surface, sealed bearings |
Accessories & Extras | BELL: Aluminum CHAINGUARD: SKS Chainblade KICKSTAND: Pletscher design, rear mount LUGGAGE SOCKET: Combo Mount FRONT LIGHT: Herrmans, 120 lumens REAR LIGHT: Herrmans FENDERS: Chromeplastic, stainless hardware RACK(S): Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity |
Motor | Bosch Performance Sport, 300% Assist, 65 Nm Torque, max speed 28 mph |
Battery | Bosch PowerPack 400 |
Controller/Display | Bosch Purion |
Charger | Compact Charger, 100-240V, 2A |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Merlot / One Size | 810067160117 | 46365 | 210000036610 |
